常用24MHZ晶振型号一览表

作者: 扬兴科技 日期:2021-10-20 浏览量:

常用24MHZ晶振型号/封装大全

图片 型号 类型 品牌 频率 工作温度 频差 电压/负载 封装尺寸 规格书下
24MHZ晶振 HC-49SMD 无源贴片晶振 YXC 24MHZ -20℃~+70℃
-40℃~+85℃
±20PPM 20PF 11.4 x 4.8 x 3.8 mm HC-49SMD无源晶振
24MHZ直插晶振 HC-49US 无源直插晶振 YXC 24MHZ -20℃~+70℃
-40℃~+85℃
±10PPM
±20PPM
12PF
15PF
16PF
20PF
11.5 x 4.5 x 3.68mm HC-49US无源晶振
24MHZ音叉晶振 YT-26M 音叉谐振器 YXC 24MHZ -20℃~+70℃ ±10PPM
±20PPMv
15PF
20PF
2.0*6.0mm (2060) YT-26M音叉晶振
24MHZ音叉晶振 YT-38M 音叉谐振器 YXC 24MHZ -20℃~+70℃ ±20PPM 20PF 3.0*8.0mm (3080) YT-38M音叉晶振
24MHZ晶振 YSX1612SL 无源贴片晶振 YXC 24MHZ -40℃~+85℃ ±10PPM 10PF 1.6x1.2mm (1612) YSX1612SL晶振
24MHZ晶振 YSX211SL 无源贴片晶振 YXC 24MHZ -40℃~+85℃ ±10PPM
±20PPM
8PF
10PF
20PF
2.0*1.6mm (2016) YSX211SL无源晶振
24MHZ无源晶振 YSX221SL 无源贴片晶振 YXC 24MHZ -20℃~+70℃
-40℃~+85℃
±10PPM
±20PPM
12PF
15PF
18PF
20PF
2.5*2.0mm (2520) YSX221SL
24MHZ贴片晶振 YSX321SL 无源贴片晶振 YXC 24MHZ -20℃~+70℃
-40℃~+85℃
±10PPM
±20PPM
8PF
10PF
12PF
15PF
18PF
20PF
3.2*2.5mm (3225) YSX321SL贴片晶振
24MHZ无源晶振 YSX531SL 无源贴片晶振 YXC 24MHZ -20℃~+70℃
-40℃~+85℃
±10PPM
±20PPM
20PF 5.0*3.2mm (5032) YSX531SL贴片晶振
24MHZ陶瓷晶振 YSX530GA 陶瓷晶振 YXC 24MHZ -20℃~+70℃
-40℃~+85℃
±10PPM
±20PPM
20PF 5.0*3.2mm (5032) YSX530GA陶瓷晶振
24MHZ有源晶振 YSO321SR  有源贴片晶振 YXC 24MHZ -20℃~+70℃
-40℃~+85℃
±20PPM
±50PPM
3.3V 3.2*2.5mm (3225) YSO321SR
24MHZ晶振 YSO531SR 有源贴片晶振 YXC 24MHZ -20℃~+70℃ ±20PPM 3.3V 5.0*3.2mm (5032) YSO531SR
24MHZ有源晶振 YSO751SR 有源贴片晶振 YXC 24MHZ -20℃~+70℃
-40℃~+85℃
±20PPM
±50PPM
3.3V 7.0*5.0mm (7050) YSO751SR有源晶振
24MHZ表贴晶振 YSO532ST 有源表贴晶振 YXC 24MHZ -20℃~+70℃
-40℃~+85℃
±20PPM
±25PPM
2.25V-5.5V 5.0*3.2mm (5032) YSO532ST
24MHZ插件晶振 YSO1512SR 有源直插晶振 YXC 24MHZ -40℃~+85℃ ±20PPM 3.3V 20.4x12.8mm YSO1512SR
24MHZ可编程晶振 YSO680PR 可编程晶振 YXC 24MHZ -40℃~+85℃ ±20PPM 3.3V 5.0*3.2mm (5032) YSO680PR可编程晶振
24MHZ可编程晶振 YSO8008MR MEMS硅晶振 YXC 24MHZ -40℃~+85℃

±20PPM
±25PPM

1.8V
3.3V
2.25V-3.63V
2.0*1.6mm (2016)
2.5*2.0mm (2520)
3.2*2.5mm (3225)
5.0*3.2mm (5032)
7.0*5.0mm (7050)
YSO8008MR可编程晶振
无源晶振24MHZ TSX-3225 无源贴片晶振 EPSON 24MHZ -40℃~+85℃ ±10PPM 8PF
9PF
10PF
12PF
16PF
3.2*2.5mm (3225) TSX-3225
贴片晶振24MHZ FA-128 无源贴片晶振 EPSON 24MHZ -40℃~+85℃ ±10PPM
±15PPM
8PF
10PF
12PF
2.0x1.6mm (2016) FA-128
24MHZ无源晶振 FA-20H 无源贴片晶振 EPSON 24MHZ -40℃~+85℃ ±10PPM 8PF
10PF
12PF
18PF
2.5*2.0mm (2520) FA-20H无源晶振
24MHZ无源晶振 FA-118T 无源贴片晶振 EPSON 24MHZ -40℃~+85℃
±10PPM
±30PPM
8PF
10PF
12PF
1.6x1.2mm (1612) FA-118t晶振
24MHZ晶振 SG-210STF 有源贴片晶振 EPSON 24MHZ -40℃~+85℃ ±50PPM 2.7~3.6V 2.5*2.0mm (2520) SG-210STF
晶振24MHZ SG-310SCF 有源贴片晶振 EPSON 24MHZ -40℃~+85℃ ±50PPM 2.7~3.6V 3.2*2.5mm (3225) SG-310晶振型号
晶振24M SG-310SEF 有源贴片晶振 EPSON 24MHZ -40℃~+85℃ ±50PPM 1.8V 3.2*2.5mm (3225) SG-310晶振型号
24MHZ有源晶振 SG5032CAN 有源贴片晶振 EPSON 24MHZ -40℃~+85℃ ±50PPM 1.6~3.6V 5.0*3.2mm (5032) SG5032CAN晶振型号
24MHZ贴片晶振 SG7050CAN 有源贴片晶振 EPSON 24MHZ -40℃~+85℃ ±50PPM 1.6~3.6V 7.0*5.0mm (7050) SG7050CAN晶振型号
24MHZ有源贴片晶振 SG7050CCN 有源贴片晶振 EPSON 24MHZ -40℃~+85℃ ±50PPM 4.5~5.5V 7.0*5.0mm (7050) SG7050CCN晶振封装
24MHZ硅晶振 SIT8008 MEMS硅晶振 SiTime 24MHZ -40℃~+85℃ ±25PPM 3.3V 2.5*2.0mm (2520)
3.2*2.5mm (3225)
5.0*3.2mm (5032)
7.0*5.0mm (7050)
SIT8008可编程晶振
硅晶振24MHZ SIT1602 MEMS硅晶振 SiTime 24MHZ -40℃~+85℃ ±25PPM 3.3V 7.0*5.0mm (7050) SIT1602可编程晶振
24MHZ温补晶振 SIT5000 温补晶振 SiTime 24MHZ -40℃~+85℃ ±25PPM 3.3V 5.0*3.2mm (5032) SIT5000温补晶振
