| 产品图片 | 晶振类型 | 晶振型号 | 封装体积 (MM) | 晶振频点 | 负载/电压 | 频差 (PPM) | 工作温度 | 样品申请 | 规格书 |
|---|---|---|---|---|---|---|---|---|---|
|
有源晶振
|
YSO170PS（新品）
|
5032/7050
|
3.3~165MHz
|
1.8V 2.5v 3.3V
|
25PPM 50PPM 100PPM
|
-40~+ 85℃
|
|
|
|
石英可编程晶振
|
YSV322PT（新品）
|
5032/7050
|
15~ 2100MHz
|
1.8V 2.5v 3.3V
|
±2.5PPM
|
-40~+ 85℃
|
|
|
|
石英可编程晶振
|
YSO511PJ（新品）
|
3225/5032/7050
|
10~2100MHZ
|
1.8V 2.5v 3.3V
|
±2.5PPM
|
-40~+ 85℃
|
|
|
|
石英可编程晶振
|
YSV311PJ（新品）
|
5032/7050
|
15~2100MHZ
|
1.8V 2.5v 3.3V
|
±25PPM ±50PPM
|
-40~+ 85℃
|
|
|
|
石英可编程晶振
|
YSO250PT（新品）
|
5032/7050
|
10~2100MHz
|
1.8V 2.5v 3.3V
|
±2.5PPM
|
-40~+ 85℃
|
|
|
|
石英可编程晶振
|
YSV221PJ（新品）
|
5032/7050
|
15~2100MHz
|
1.8V 2.5v 3.3V
|
±25ppm ±50ppm
|
-40~+ 85℃
|
|
|
|
石英可编程晶振
|
YSO211PR（新品）
|
3225/5032/7050
|
150~2100MHz
|
1.8V 2.5v 3.3V
|
±25ppm ±50ppm
|
-40~+ 85℃
|
|
|
|
石英可编程晶振
|
YSO692PR（新品）
|
3225/5032/7050
|
150~250MHz
|
1.8V 2.5v 3.3V
|
±25ppm ±50ppm
|
-40℃~+ 85℃
|
|
|
|
有源晶振
|
YSO231LJ（新品）
|
2520/3225/5032/7050
|
150~250MHz
|
1.8V 2.5v 3.3V
|
±25PPM ±50PPM
|
-40~+125℃
|
|
|
|
石英可编程晶振
|
YSO691ER（新品）
|
5032/7050
|
1~200MHz
|
1.8V 2.5V 3.3V
|
±30PPM
|
-40℃~+85℃
|
|
|
|
有源晶振
|
YSO150HT（新品）
|
1612/2016/2520/3225/5032/7050
|
1~54MHz
|
1.8V~3.3V
|
±50PPM ±80PPM
|
-40℃~+125℃
|
|
|
|
宽电压晶振
|
YSO110TR
|
1612/2016/2520/3225/5032/7050
|
1~54MHz
|
1.8V~3.3V
|
±10PPM ±20PPM
|
-40℃~+85℃ -40℃~+125℃
|
|
|
|
石英有源晶振
|
YSO120TK
|
1612/2016/2520/3225/5032/7050
|
32.768KHz
|
1.8V~3.3V
|
±10PPM ±20PPM
|
-40℃~+85℃ -40℃~+125℃
|
|
|
|
高电压晶振
|
YSO130HR
|
3225/5032/7050
|
1~100MHz
|
5V
|
±10PPM ±20PPM
|
-40℃~+85℃
|
|
|
|
低抖动晶振
|
YSO690PR
|
2016/2520/3225/5032/7050
|
1~200MHz
|
1.8V 2.5V 3.3V
|
±20PPM ±25PPM ±50PPM
|
-40℃~+85℃
|
|
|
|
低功耗晶振
|
YSO8008MR
|
2016/2520/3225/5032/7050
|
1~110Mhz
|
1.8V 2.5V 2.8V 3.0V 3.3V
|
±20PPM ±25PPM ±50PPM
|
-20℃~+70℃ -40℃~+85℃
|
|
|
|
低功耗振荡器
|
YSO8009MR
|
2016/2520/3225/5032/7050
|
115~137Mhz
|
1.8V 2.5V 2.8V 3.0V 3.3V
|
±20PPM ±25PPM ±50PPM
|
-20℃~+70℃ -40℃~+85℃
|
|
|
|
低频差分晶振
|
YSO9121MR
|
3225/5032/7050
|
1~220Mhz
|
2.5V 3.3V 2.25V~3.63V
|
±10PPM ±20PPM ±25PPM ±50PPM
|
-20℃~+70℃ -40℃~+85℃
|
|
|
|
高频差分晶振
|
YSO9122MR
|
3225/5032/7050
|
220~625Mhz
|
2.5V 3.3V 2.25V~3.63V
|
±10PPM ±20PPM ±25PPM ±50PPM
|
-20℃~+70℃ -40℃~+85℃
|
|
|
|
高温晶振
|
YSO8918MR
|
2016/2520/3225/5032/7050
|
1~110Mhz
|
1.8V 2.5V 2.8V 3.0V 3.3V
|
±20PPM ±25PPM ±30PPM ±50PPM
|
-40℃~+105℃ -40℃~+125℃
|
|
|
|
高温晶振
|
YSO8920MR
|
2016/2520/3225/5032/7050
|
1~110Mhz
|
1.8V 2.5V 2.8V 3.0V 3.3V
|
±20PPM ±25PPM ±30PPM ±50PPM
|
-55℃~+125℃
|
|
|
|
低抖动晶振
|
YSO8208MR
|
2520/3225/5032/7050
|
1~80Mhz
|
1.8V 2.5V 2.8V 3.3V
|
±10PPM ±20PPM ±25PPM ±50PPM
|
-20℃~+70℃ -40℃~+85℃
|
|
|
|
低抖动晶振
|
YSO8209MR
|
2520/3225/5032/7050
|
80.000001~220Mhz
|
1.8V 2.5V 3.3V
|
±10PPM ±20PPM ±25PPM ±50PPM
|
-20℃~+70℃ -40℃~+85℃
|
|
|
|
压控晶振
|
YSV310PR
|
3225/5032/7050
|
10~250MHz
|
2.5V 3.3V
|
±50PPM
|
-40℃~+85℃
|
|
|
|
差分可编程
|
YSO210PR
|
3225/5032/7050
|
10~1500MHz
|
2.5V 3.3V
|
±50PPM
|
-40℃~+85℃
|
|
|
|
压控差分晶振
|
YSV220PR
|
3225/5032/7050
|
10~1500MHz
|
2.5V 3.3V
|
±50PPM
|
-40℃~+85℃
|
|
|
|
有源可编程晶振
|
YSO680PR
|
2520/3225/5032/7050
|
1~108MHz
|
1.8V 2.5V 3.3V
|
±20PPM ±25PPM ±50PPM
|
-40℃~+85℃
|
|
|
|
车规级有源晶振
|
YSO140TC
|
1612/2016/2520/3225/5032/7050
|
1~54MHz
|
1.8V~3.3V
|
±50PPM ±100PPM
|
-40℃~85℃ -40℃~125℃
|
|
|
|
差分定频晶振
|
YSO230LR
|
2520/3225/5032/7050
|
13.5〜200MHz
|
1.8V~3.3V
|
±50ppm
|
-40℃~+85℃
|
|
|
|
有源晶振DIP
|
YSO1512SR
|
20.4x12.8x5.3mm
|
1~100MHz
|
3.3V 5V
|
±20PPM ±25PPM
|
-20℃~+70℃ -40℃~+85℃
|
|
|
|
有源晶振DIP
|
YSO1212SR
|
12.7x12.7x5.4mm
|
1~100MHZ
|
3.3V~5V
|
±20PPM ±25PPM
|
-20℃~+70℃ -40℃~+85℃
|
|
